All Generator Sets Equipped With EMCP II Control Panels Do not perform any procedure outlined in this Special Instruction until you have read and understood this information.Reference: Service Manual "Electronic Modular Control Panel II (EMCP II)", SENR5809, for MUI Engines.Service Manual "Electronic Modular Control Panel II (EMCP II) For Electronically Controlled Engines", SENR5827, for PEEC Engines.Service Manual "Electronic Modular Control Panel II (EMCP II) For Electronic Unit Injector (EUI) Engines", SENR5398.Service Manual "Programmable Relay Control Module (PRCM)", SENR6588.Owner's Manual "Customer Communiions Module For Electronic Modular Control Panel II (EMCP II)", SEBBU6874.Service Manual "Electronic Modular Control Panel II+ (EMCP II+) For MUI Engines", SENR5832.Service Manual "Electronic Modular Control Panel II+ (EMCP II+) For PEEC Engines", RENR1254.Recommended Tools
Parts Required
Introduction
This Special Instruction provides information on the equipment and procedures necessary to successfully upgrade into the new Electronic Modular Control Panel II+ (EMCP II+) from any existing EMCP II equipped Generator Set.
Illustration 1. Loion Of EMCP II+ System Components On Instrument Panel:
(1) Generator set control + (GSC+). (2) Governor switch (GS) [optional] or speed potentiometer (SP) [optional]. (3) Starting aid switch (SAS) [optional]. (4) Engine control switch (ECS). (5) Alarm module (ALM) [optional]. (6) Custom alarm module (CAM) [optional] or synchronizing light module (SLM) [optional]. (7) Panel light switch (PLS) [optional]. (8) Emergency stop push button (ESPB). (9) Voltage adjust rheostat (VAR).
Illustration 2: Loion Of EMCP II+ System Components On Interior Of Instrument Panel And Sub Panel Instrument Panel:
Instrument Panel (Top View With Door Open). (1) Generator set control + (GSC+). (2) Governor switch (GS) [optional] or speed potentiometer (SP) [optional]. (3) Starting aid switch (SAS) [optional]. (4) Engine control switch (ECS). (5) Alarm module (ALM) [optional]. (6) Custom alarm module (CAM) [optional] or synchronizing light module (SLM) [optional]. (7) Panel light switch (PLS) [optional]. (8) Emergency stop push buttom (ESPB). (9) Voltage adjust rheostat (VAR). (10) Relay module (RM) [part of GSC+].
Sub Panel (Front View). (11) Auxiliary terminal strip (AUX). (12) Electronic governor (EG) [optional]. (13) AC transformer box + (ATB+). (14) Fuel control timer module (FCTM) [ETS only]. (15) Circuit breaker 2 (CB2). (16) Kilowatt level relay (KWR). (17) Engine failure relay (ENFR) [optional]. (18) Auxiliary relay (AUXREL) [optional]. (19) Starting motor magnetic switch 1 (SMMS1). (20) Starting motor magnetic switch 2 (SMMS2) [optional]. (21) Fuse 11 (F11). (22) Slave relay (SR) [ETR only]. (23) Ground post high voltage (GPHI). (24) Emergency fuel control relay (EFCR) [ETS only] or auxiliary fuel control relay (AFCR). (25) Fuse 16 (F16). (26) Fuse 12 (F12).Procedure
1. Start the engine of the generator set prior to initiating the upgrade procedure. Verify that all systems are operational. Repair any faults that are logged prior to the conversion.2. Shut down the generator set. Record all set point information for reprogramming of the EMCP II+ Genset Control, including current hour meter reading. Disconnect the battery system by either turning OFF the battery disconnect switch or removing the ground wire from the negative terminal of the batteries.
Illustration 3. AC Transformer Box + (ATB+) (Front View): (a) H21. (b)
