Disassembly Procedure
Table 1
Required Tools
Tool Part Number Part Description Qty
A 1P-0510 Driver Gp 1
B - 1 inch by 4 inch steel plate 2
C 248-3311 Holding Fixture 1
D 248-3310 Spanner Wrench 1
E 8H-0663 Bearing Puller Gp 1 Start By:
Remove the auxiliary water pump. Refer to Disassembly and Assembly, "Auxiliary Water Pump - Remove".
Illustration 1 g01036014

Remove O-ring seal (6). Remove nut (7) and the washer. Remove coil assembly (8) .
Repeat Steps 3 through 1 for the remaining modulating valves.Installation Procedure
Keep all parts clean from contaminants.Contaminants may cause rapid wear and shortened component life.
Note: Inspect the O-ring seals, the seals, and the gaskets. Replace the O-ring seals, the seals
