3208, 3304, 3306 EnginesThere are two types of 3P1567 Dial Indiors and a contact point for each type. If the wrong contact point is used with the dial indior, it is possible that the measurement will not be correct for fuel setting or fuel ratio control setting.
The earlier 3P1567 Dial Indiors did not have a return spring, (but return springs have been added to many of these indiors). The total measurement range for the earlier indior is approximately .8" (20 mm). The 5P6531 Contact Point is 2.25" (57.2 mm) long and is used with the earlier indiors either with or without return springs.
The later 3P1567 Dial Indiors have a return spring. The total measurement range for the later indior is approximately 1" (25 mm). The 5P4809 Contact Point is 2.00" (50.8 mm) long and is used with the later indiors.
Since the return spring is not a good identifiion of earlier or later types, it is necessary to measure the dial indior with the contact point installed. See dimension A in the illustration. If the correct contact point is used, dimension A will be approximately 3" (76 mm). If dimension A is not approximately 3" (76 mm), the wrong contact point is used.
When the dial indior and contact are installed in the fuel system and the large hand of the indior is to be put on zero, be sure the indior is not moved down more than .08" (2 mm) which is two revolutions of the large hand from the free position (no force on the contact point).
Dial indior and contact point.
