TRACK-TYPE TRACTOR D6K LGP D6N D6R III D6T
TRUCK 785B 785C 785D
WHEEL SCRAPER 621G 623E 623F 623G 627E 627G
WHEEL TRACTOR 621E 621F 621G 621H 623H 627E 627F 627H
WHEEL TRACTOR-SCRAPER 623K 623K LRC



Typical example
Table 1
Specifiion for 335-6218 Cylinder Head Gp, 285-3086 Cylinder Head Gp, and 317-2440 Cylinder Head Gp
Item Qty Part Specifiion Description
1 4 316-5976 Spring Length under test force is 60.29 mm (2.374 inch).
Test force is 460 23 N (103 5 lb).
Free length after test is 74.8 mm (2.94 inch).
2 4 316-5977 Spring Length under test force is 57.5 mm (2.26 inch).
Test force is 248.0 12.4 N (55.8 2.8 lb).
Free length after test is 71.4 mm (2.81 inch).
3 2 316-5980 Valve Stem Seal Install the valve stem seal to the inlet valves.
A - - Height from the top of the cylinder head to the top of the valve guides is 26.0 1.0 mm (1.02 0.04 inch).
4 2 316-5981 Washer Install the washer to the exhaust valves.
5 2 197-6995 Valve Guide Bore of the exhaust valve guide after installation is 12.619 0.025 mm (0.4968 0.0010 inch).
6 2 133-9306 Valve Guide Bore of the inlet valve guide after installation is 9.487 0.025 mm (0.3735 0.0010 inch).
7 2 194-4897 Exhaust Valve Before assembly, coat the exhaust valve stems with clean engine oil.
Stem diameter is 12.464 0.025 mm (0.4907 0.0010 inch).
Face angle is 44.40 0.25 degrees.
8 2 210-2542 Inlet Valve Before assembly, coat the inlet valve stems with clean engine oil.
Stem diameter is 9.441 0.010 mm (0.3717 0.0004 inch).
Face angle is 19.40 0.25 degrees.
9 2 130-2608 Valve Seat Insert (Exhaust) Diameter of exhaust valve seat insert is 60.119 0.015 mm (2.3669 0.0006 inch).
Bore in the cylinder head is 60.000 0.025 mm (2.3622 0.0010 inch).
Face angle is 45.00 0.25 degrees.
10 2 130-2607 Valve Seat Insert (inlet) Diameter of inlet valve seat insert is 60.627 0.015 mm (2.3869 0.0006 inch).
Bore in the cylinder head is 60.508 0.025 mm (2.3822 0.0010 inch).
Face angle is 20.00 0.25 degrees.
