1J2674 RING-WEAR parts 5230, 630B, 631B, 633, 641B, 7A, 7G, 8A, 8B, 8D, 977, 977H, 980, 988, D5B, D5E, D6D, D6E, D6F SR, D6G, D6G SR, D6G2 XL, D8N, D8R, D8R II, D8T, D9G, D9R, D9T

8M4228 RING parts 1190T, 1290T, 2391, 2491, 365B, 365B II, 365C, 385C, 385C FS, 5080, 5090B, 5130, 522, 522B, 532, 552, 552 2, 769, 795F AC, 795F XQ, 797, 797B, 797F, 950G, 950G II, 962G, 962G II, 966D, 966F, 966F II, ...

9J0711 RING-WEAR parts 10S, 5110B, 5130, 5130B, 844, 844H, 854G, 854K, 966D, 992C, D10, D11N, D11R, D11T

3G5098 RING-WEAR parts 950B, 950B/950E, 950F, 950F II, 960F, 980C, 980F, 980F II, 980G, 980G II, 980H

8M4228 Ring WEAR - Fits: 522 795F 552 797F 385C 365C 992D 970F 972G 966G 797B 769 970F
GEN Compatible Models - 522 795F 552 797F 385C 365C 992D 970F 972G 966G 797B 769 970F || Related Items - 2350974 1946174 1979121 1096175 || STEERING CYL GP

3516 Industrial ( 27Z ),
Marine ( 29Z ) And Generator Set ( 25Z ) EnginesDescription of Change: A bracket has been added to the watercooled exhaust manifold group used on the above 3516 Engines. The new bracket fits between the right side exhaust manifold outlet flange and the flywheel housing. The new bracket will help reduce the stress that can crack the weld in the rear portion of the right side exhaust manifold. It will also help support and reduce vibration of the turbocharger. Some material has been added to the manifold outlet flange to attach the new bracket.Adaptable As: The new components of the 1W5937 Manifold Group are listed in the chart. The new components, when used together are a direct replacement for the former manifold. The loion of the new components are shown in Illustration 3. The new 7C700 Bracket Assembly can be added to earlier engines if the exhaust manifold is modified. See the procedure that follows.
Procedure To Modify Right Hand Exhaust Manifold
1. Remove the right hand turbocharger.2. Make a plate from high strength structural steel as shown in Illustration 1.
Illustration 1. Dimensions for plate.3. Weld the plate (made in Step 2) to the right side exhaust manifold outlet flange as shown in Illustrations 2 and 3. Be sure the welder is grounded to the right side exhaust manifold when welding the plate to the manifold. Do not ground the welder to the cylinder block or frame rails because electrical arcing may damage the engine bearings.4. Install the 7C700 Bracket Assembly on the flywheel housing with two 6H1717 Bolts and two 5P1076 Washers. See Illustration 4. Use the 7C700 Bracket Assembly as a template to mark the loion of the holes on the plate that was welded to the manifold.
Illustration 2. Loion of the plate (from Step 2) on to the right side exhaust manifold.
Illustration 3. Loion and welding instructions for welding the plate (from Step 2) on the right side exhaust manifold.5. Remove the 7C700 Bracket Assembly from the flywheel housing.6. Drill two 8.20 mm (.323") diameter holes through the plate at the loions marked in Step 4. Tap the two holes for 3/8" -16 threads.7. Install the 7C700 Bracket Assembly on the flywheel housing. Fasten the bracket assembly to the exhaust manifold with two L1351 Bolts and two 9L9132 Washers.
Illustration 4. Loion of the new components in the 1W5937 Exhaust Manifold Group.8. Install the turbocharger on the exhaust manifold.
